| Camera |
| Image Sensor | 1/2.8" CMOS |
| Pixel | 5 MP |
| Max. Resolution | 2560 (H) × 1920(V) |
| ROM | 128 MB |
| RAM | 128 MB |
| Electronic Shutter Speed | 1 s–1/100,000 s |
| Scanning System | Progressive |
| Min. Illumination | 0.05 lux@F1.6 (Color, 30 IRE); 0.005 lux@F1.6 (B/W, 30 IRE); |
| Illumination Distance | 30 m (98.43 ft) (warm light); 30 m (98.43 ft) (IR); |
| Illuminator On/Off Control | Manual; auto; off |
| Illuminator Number | 2 (IR light); 2 (warm light) |
| Lens |
| Focal Length | 4.0 mm |
| Max. Aperture | F1.6 |
| Field of View | H: 80.4°; V: 58.1°; D: 104.8° |
| Close Focus Distance | 0.3 m (0.98 ft) |
| Iris Control | Fixed |
| DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| 4.0 mm | 77.4 m ( 253.94 ft) | 31.0 m ( 101.71 ft) | 15.5 m ( 50.85 ft) | 7.74 m ( 25.39 ft) |
| PTZ |
| Pan/Tilt Range | Pan: 0° to 345°; Tilt: 0° to +80° |
| Manual Control Speed | Pan: 0.1°–74°/s; Tilt: 0.1°–36.4°/s |
| Preset Speed | Pan: 0.1°–62°/s; Tilt: 0.1°–36.3°/s |
| Preset | 300 |
| Power-off Memory | Yes |
| Idle Motion | Preset |
| Smart Event |
| IVS | Tripwire; intrusion |
| Human Detection | Yes |
| Intelligence |
| SMD | SMD 3.0 |
| Active Deterrence |
| Light Warning | Warm light warning; Flash duration: 5 s–30 s; Flash frequency: high, medium, low |
| Sound Warning | Offers 1 sound alarm and 10 custom sound alarms can be imported; Sound can be set from 0%–100%; Play times can be set from 1-10. |
| Video |
| Video Compression | Smart H.265+;H.265;Smart H.264+;H.264B;H.264M;H.264H;MJPEG(Sub Stream 1) |
| Streaming Capability | 2 streams |
| Resolution | 5M (2560 × 1920); 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240) |
| Video Frame Rate | Main stream: 5M/4M/3M/1080p/1.3M/720p@(1–25/30 fps) Sub stream 1: D1/VGA/CIF@(1–25/30 fps) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H264: 104 kbps-8,192 kbps H265: 41 kbps-8,192 kbps |
| Day/Night | Auto (ICR); Color/B/W |
| BLC | Yes |
| WDR | DWDR |
| HLC | Yes |
| White Balance | Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp |
| Gain Control | Auto; manual |
| Noise Reduction | 2D NR; 3D NR |
| Motion Detection | Yes |
| Region of Interest (RoI) | Yes |
| Defog | Electronic |
| Image Rotation | 180° |
| Privacy Masking | 4 area |
| S/N Ratio | ≥55 dB |
| Audio |
| Audio Compression | PCM；G.711a；G.711Mu；G.726；AAC； |
| Network |
| Network Port | RJ-45 (10/100 Base-T) |
| Network Protocol | HTTP;HTTPS;TCP/IP;IPv4;RTSP;UDP;SMTP;NTP;DHCP;DNS;DDNS;IPv6;SSL;FTP;ARP;RTCP;RTP;IP Filter;RTMP |
| Interoperability | CGI;SDK;ONVIF (Profile S & Profile T);RTMP;P2P |
| Streaming Method | Unicast/Multicast |
| User/Host | 20 (total bandwidth: 64 M) |
| Storage | Micro SD card (256 GB); FTP |
| Browser | IE: IE 7 and later versions; Chrome; Firefox; Safari |
| Management Software | Smart PSS;DMSS;Player;ConfigTool;NVR;Smart Player |
| Mobile Client | iOS;Android |
| Certification |
| Certifications | CE: EN55032/EN50130-4/EN IEC61000-3-3/EN IEC61000- 3-2/EN55024/EN55035/EN62368-1 FCC: 47 CFR FCC Part15, Subpart B, ANSI C63.4:2014 |
| Port |
| Audio Input | 1 channel (built-in mic) |
| Audio Output | 1 channel (built-in speaker) |
| Alarm Linkage | Capture; preset; recording; audio; sending email |
| Alarm Event | Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
| Power |
| Power Supply | 12 VDC/1.5 A ± 10% PoE (802.3af) |
| Power Consumption | Basic: 3.5 W; Max: 10 W (illuminator) |
| Power Adapter | Optional |
| Environment |
| Operating Temperature | –30 °C to +55 °C (–22 °F to +131 °F) |
| Operating Humidity | ≤95% |
| Protection | TVS 2000 V lightning proof; surge protection; voltage transient protection;Waterproof and Dustproof |
| Structure |
| Product Dimensions | 140.5 mm × Φ111.0 mm (5.53" × Φ4.37") |
| Net Weight | 0.5 kg (1.10 lb) |
| Gross Weight | 1 kg (2.20 lb) |
| Filter |
| Remarks | * The precision of the presets for PTZ cameras might vary depending on different series. For scenes with high requirements on the precision, contact your local sales representative for assistance with selecting the model |
