| Performance |
| Model | DHI-ISC-EAA8-C201-P | DHI-ISC-EAA8-C211-P | DHI-ISC-EAA8-C208-P | DHI-ISC-EAA8-C218-P | DHI-ISC-EAA8-C201-R |
| Technology | Acousto-Magnetic Antenna |
| Detection Frequency Band | 58 kHz |
| Detection Distance of EAS Labels | 1.8 – 2.0 m (5.91 ft – 6.56 ft) (Distance of two antennas) * depending on environment |
| Detection Distance of EAS Tags | 2.0 – 2.4 m (6.56 ft – 7.87 ft) (Distance of two antennas) * depending on environment |
| Alarm Volume | Max 90 dB (Adjustable) |
| Antenna Type | Primary antenna | Primary antenna | Primary antenna | Primary antenna | Replica antenna |
| Adaptability | A single primary antenna can connect to two replica antennas simultaneously |
| Sound and Light Alarm | Primary and Replica Antenna |
| Certifications |
| Certifications | IEC 60068-2-1
IEC 60068-2-2
CE-LVD: Low Voltage Directive 2014/35/EU
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
CE-RED: Radio Equipment Directive 2014/53/EU |
| RoHS | Conform with RoHS
Directive 2011/65/EU, 2015/863/EU and REACH regulations as
defined in EC No 1907/2006 and subsequent amendments. |
| Safety | ICNIRP 2010 Guidelines
ICNIRP 1998 Guidelines
EC directive 2013/35/EU
EC recommendation 1999/519/EC
IEEE C95.1:2005
EN IEC 62311:2020
EN 50364:2010
EN 62369-1:2010 |
| Ports |
| TR Board Port (CH1, CH2, CH3) | CH1 integrates into the main board, CH2 and CH3 can connect to the TR board as needed. | NA |
| CCTV Port | Output port for the linkage signal of the camera, up to 3 cameras can be connected simultaneously. | NA |
| Network Interface | RJ45 | NA |
| Power Interface | HTTP, TCP/IP | NA |
| Power Interface | SDK | NA |
| Power Interface | DSS Pro, Configtool | DSS Pro, Configtool | DSS Pro, Configtool, WISS | DSS Pro, Configtool, WISS | NA |
| Regular Parameters |
| Shell Material | ABS and acrylic |
| Shell Color | Transparent and white |
| Input Voltage | 220 – 240 VAC @ 50 Hz / 60 Hz | 100-130 VAC @ 50 Hz / 60 Hz | 220 – 240 VAC @ 50 Hz / 60 Hz | 100-130 VAC @ 50 Hz / 60 Hz | 24 VAC @ 50 Hz / 60 Hz |
| Output Voltage | 24 VAC / 3 A | 24 VAC / 3 A | 24 VAC / 3 A | 24 VAC / 3 A | NA |
| Maximum Power Consumption | 25 W | 25 W | 25 W | 25 W | 23 W |
| Typical Power Consumption | 20 W | 20 W | 20 W | 20 W | 18 W |
| Overall Exterior Size | 1521 mm × 360 mm × 134 mm (59.9'' × 14.2'' × 5.3'') |
| Packing Size of Primary / Replica Antenna | 1665 mm × 460 mm × 210 mm (65.6'' × 18.1'' × 8.3'') |
| Gross Weight | 21.0 kg (46.29 lb) | 21.0 kg (46.29 lb) | 21.0 kg (46.29 lb) | 21.0 kg (46.29 lb) | 18.5 kg (40.79 lb) |
| Operating Temperature | 0 °C to 45 °C ( 32 °F to 113 °F) |
| Operating Humidity | 0 % – 95 % (RH) |
| Installation | Vertical pole mount |
