LS460UDM-UF

Overview Specifications Download Sales Enquiry
LS460UDM-UF
Compare Favourites
LS460UDM-UF

46'' FHD Video Wall Display Unit (Ultra Narrow Bezel 1.7mm)

Key Points
    ·Industrial level ADS LCD panel, suitable for continuous 24/7operation
    ·Ultra-narrow 1.7mm B-to-B (Panel Bezel to Panel Bezel)design
    ·Anti-glare panel, vivid and memorable image quality
    ·Factory calibration technology for color uniformity
    ·Built-in 3D noise reduction system and picture splicingfunction
    ·Abundant interfaces HDMI, DVI, VGA, DP (UHD daisy chain),RS232, Audio
    ·Up to 4K@60Hz signal input by DP IN or HDMI 1 interface,up to 4K@30Hz signal output by DP OUT interface
    ·Infrared, RS232 dual mode, supporting remote control bycomputer
    ·Professional thermal design to extend device lifespan
    ·Built-in power, low energy consumption, ultra-quiet
    ·Modular structure design, multiple installation modes
    ·Widely used in surveillance center, command center,meeting room, commercial display scenes, etc.
Sales Enquiry
Datasheet
LS460UDM-UF

Specifications

Model

Model

DHI-LS460UDM-UF

Display

Diagonal Size

46"(16:9)

Panel Type

ADS

Resolution

1920×1080 (FHD)

Bezel width

B2B: 1.7mm (Panel Bezel to Panel Bezel), 0.9mm (T/L),

0.8mm (B/R)

A2A: 2.45mm (Active area to Active area), 1.5mm (T/L),

0.95mm (B/R)

Backlight

Direct LED

Brightness

500 cd/m²

Contrast Ratio

1200:1

Pixel Density

48dpi

Viewing Angle

H178°, V178°

Response Time (G-to-G)

8ms

Color Depth

8bit (16.7M)

Color Temperature

10,000K

Surface Treatment

Haze 25%, 3H

MTBF

50,000h

Signals

Input

VGA(D-Sub)×1, DVI-D×1, HDMI×2, DP×1, RS232×1, Audio×1, IR×1

Output

DP×1, RS232×1, Audio×1

General

Power Supply

AC100V～AC240V, 50/60 Hz

Power Consumption (Standby)

<0.5W

Power Consumption (Typical)

120W

Power Consumption (Max.)

140W

Energy Efficiency Class (EU)

G

Installation Mode

Floor-standing, wall-mounted

VESA

600×400mm, M6

Control Mode

Infrared, RS232 dual mode, supporting remote control by computer

Gross Weight

25.1kg (55.3Ib)

Net Weight

17.9kg (39.5Ib)

Product Dimension (W×H×D)

1021.2mm×575.8mm×122.7mm (40.2"×22.7"×4.8")

Package Dimension (W×H×D)

1200mm×815mm×265mm (47.2"×32.1"×10.4")

Operating Environment

Temperature

0℃~+50℃

Humidity

10%RH~80%RH (non-condensing)
